© 2006 Directed Electronics—all rights reserved
62
long term event history
The system stores the last two full triggers in memory. These are not erasable. Each time the unit sees a
full trigger, the older of the two triggers in memory will be replaced by the new trigger. To access long term
event history:
1. With the ignition off, press and HOLD the Valet/Program switch.
2. Turn on the ignition.
3. Release the Valet/Program switch.
4. Press and release the Valet/Program switch within 5 seconds. The
LED will flash in groups indicating the last two zones that triggered
the unit for one minute or until the ignition is turned off. Refer to
table of zones.
NOTE: The Warn Away triggers are not stored to memory and will not be reported.
