Directed Electronics PYTHON 1090 - Heavy Gauge Inline Connector Key Switch Interface; Remote Start Harness (H3), 5-Pin Connector; Horn, Channel 6 (H4), 2-Pin Connector

© 2006 Directed Electronics—all rights reserved
20
heavy gauge inline connector key switch interface
1
PURPLE (+) STARTER OUTPUT TO STARTER (STARTER SIDE)
2
GREEN STARTER INPUT FROM IGNITION (KEY SIDE)
3
RED (+) high (30A) current 12v input
4
ORANGE (+) output to accessory circuit
5
PINK (+) output to primary ignition circuit
6
RED (+) (30A) high current 12v input
7
PINK/WHITE (+) output to second ignition circuit
8
RED/WHITE (+) (30A) high current 12v input
remote start harness (H3), 5-pin connector
H3/1
BLACK/WHITE (-) neutral safety switch input
H3/2
VIOLET/WHITE tachometer input wire
H3/3
BROWN (+) brake shutdown wire
H3/4
GRAY (-) hood pinswitch input, zone 1
H3/5
BLUE/WHITE (-) 200 ma 2nd status/rear defogger- latched/pulsed
horn, channel 6 (H4), 2-pin connector
H4/1
ORANGE/BLACK CHANNEL 6 OUTPUT
H4/2
BROWN (-) 200ma HORN
