Directed DIRECTWIRE DIRECTECHS 933.TL14

11
933.TL14 1.02.198.9 2023 Toyota Camry
©2023 VOXX•DEI LLC. All rights reserved.
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color Connection
H4/6 Green No Connection No Connection
H4/7 Violet No Connection No Connection
H4/8 Orange No Connection No Connection
H4/9 Red/White No Connection No Connection
H4/10 Pink No Connection No Connection
RF Port harness, 2-pin white connector (H5)
Module
Conn./Pin Color Description
H5/1 N/A RF Loop
H5/2 N/A RF Loop
D2D harness, 4-pin white (1) and black (2) connectors (H6)
Module
Conn./Pin Color Description
H6/1 Blue (Data) TX
H6/2 Black (-) Ground
H6/3 Green (Data) RX
H6/4 Red (+) 12 Volt
Temperature sensor harness, 2-pin black connector (H7)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color Connection
H7/1 Black Temperature Sensor
H7/2 Black Temperature Sensor
