4
IP2368EN
EN
2. EC Declaration of Conformity
Entrematic Group AB declares that the Ditec LCA70 control panel is compliant with the fundamental
requisites and other relevant requirements defined down by the following EC directives:
EMC Directive 2014/30/EU;
Low Voltage Directive 2014/35/EU.
RoHS Directive 2011/65/EU
Landskrona, 10-07-2020 Matteo Fino
(President & CEO)
3. Technical specifications
Power supply 230V~ 50Hz
Power absorption 4A max
Fuses
F1= F5 A (Motor driver circuits)
F2= T3.15 A (Electric lock circuit)
Motor output 230V AC 50Hz; 2 x 2A max; 1 x 4A max
Permanent power supply to accessories 0-30 24V
0.3A max
WARNING: the total sum of the
current values delivered from the
24V~ outputs 30 and 1 must never
exceed 0.3A.
Power supply to accessories 0-1 24 V
0.3 A max
24V~ accessory power supply 24V~ 0.3A max
Electric lock output
12V~ 15W (max 3s)
12V~ 0.1A (continuous)
230V~ flashing light output 25W max
Ambient temperature -20°C - +55°C
Storable radio codes 100/200 see RO → MU → 10/20 (Paragraph 11.5)
Radio frequency
433.92 MHz (prod. code ZENRS included) or 868.35 MHz (prod.
code ZENPRS optional)
Degree of protection of the container IP55
Product size 187x261x103mm
NOTE: The given operating and performance features can only be guaranteed with the
use of DITEC accessories and safety devices.
1.1 Safety functions
The Ditec LCA70 control panel has the following safety functions:
- obstacle recognition with force limiting.
The maximum response time of the safety functions is 0.5s. The reaction time to a faulty safety
function is 0.5s.
The safety functions comply with the standards and performance level indicated below:
EN ISO 13849-1:2015 Category 2 PL=c
The safety function cannot be bypassed either temporarily or automatically. Fault exclusion has
not been applied.
