Remote Controller Controls
With the buttons on the DJI RC Plus remote controller, users can switch display modes between
point cloud and visible light live views, preview the point cloud eect, and control the gimbal
and camera.
1. L1/L2/L3/R1/R2/R3 Buttons
Go to Camera View in DJI Pilot 2 to view the
specic functions of these buttons. Refer to
the DJI Pilot 2 App section for details.
2. 5D Button
View and customize the 5D button functions
in DJI Pilot 2.
3. Customizable C1/C2/C3 Buttons
Customize the function of these buttons in
DJI Pilot 2.
4. Left Dial
Adjust the tilt of the gimbal.
5. Record Button
Press once to start or stop recording.
6. Focus/Shutter Button
Press the button halfway down for
autofocus and all the way down to take a
photo.
7. Right Dial
Adjust the pan of the gimbal.
