DMM DYN4 Series - Page 35

35
DMM Technology Corp.
DYN4 AC Servo Drive Instruction Manual
REV. ZM7-A10A
CT1
█ Connection Example
♦ Line Drive Output
♦ Open Collector Output - External Power Supply
♦ Open Collector Output - Internal Power Supply
270Ω
11
23
270Ω
22
10
PUL+, A+, CW+
PUL-, A-, CW-
DIR+, B+, CCW+
DIR-, B-, CCW-
270Ω
11
23
24+5VDC
1,9,12GND
270Ω
22
10
PUL+, A+, CW+
PUL-, A-, CW-
DIR+, B+, CCW+
DIR-, B-, CCW-
270Ω
11
23
270Ω
22
10
PUL+, A+, CW+
PUL-, A-, CW-
DIR+, B+, CCW+
DIR-, B-, CCW-
VDC
