32 XR150FC/ XR550FC User’s Guide Appendix C
C mm Keypad Displays
Listed below are several keypad messages you may see on the display. Follow the instructions in the Possible Solutions column to
correct the problem. In many cases, you need to call a service person to correct the problem. Displays that are not discussed here
mean that your service representative should be called.
Message Mea i g P ssible S luti s
INVALID AREA
The user has attempted a door access to an area they
are not assigned.
Change the user access areas if access to the area is
needed. If access is not needed, the user cannot enter
the area.
INVALID CODE
The user code you entered is not recognized by the
system.
Check the user code and try again.
INVALID PROFILE
A user has attem pted a function that is outside of the
assigned pro¿le.
Check the user pro¿le settings.
INVALID TIME
A user code assigned to a speci¿c schedule was
entered outside of the valid schedule.
See Schedules and User Codes.
Check the system clock.
ENTER 2ND CODE
The area you are attempting to disarm or access is a
Two Man Area.
A second and different user code must be entered.
CLOSING TIME!
The scheduled has expired and in a short time the area
will automatically arm.
Users still on the premise should arm the system or
extend the schedule to a later tim e.
LATE TO CLOSE
The system was not armed at i ts scheduled closing
time.
Users still on the premise should arm the system or
extend the schedule to a later tim e.
FAILED TO EXIT
A user assigned th e anti-passback option has
attempted to re-enter an area from which they did not
exit properly.
The user must exit the area through the proper door. If
not possible, your system administrator should select the
Forgive option in the User Codes menu.
Appe dix C
