Technical description MC402
20
6.1 Control elements on the moniceiver
Front
Rear
No. in
fig. 2, page 3
Description Description
1 EJECT button Ejects the disc from the disc
compartment
2 MENU button Switches between the main menu and
the audio/video source menu
3 ON/OFF/VOLUME knob • Switches the device on and off
• Controls the volume
• Switches to mute
• Controls the brightness
4 BRIGHTNESS button Enables the setting of the brightness of
the display
5 RESET button Resets the device
6 AV input Audio/video input for external device,
3.5 mm stereo jack
7 USB port Port for USB flash drive
8 Slot for SD or MMC memory
card
Slot for memory cards
9 Touch screen Display with touch input
10 Disc compartment Slot for CDs, VCDs and DVDs
No. in
fig. 3, page 4
Description
1 Wiring harness
2 Fuse (15 A)
3 ISO plug for connection of audio / video devices in the vehicle
4 Audio video system input
5 Radio antenna input
