MC402 Technical data
65
17 Technical data
Radio
PerfectView MC402
Ref. no.: 9600000350
Operating voltage: 12 Vg (10.5V–15.8V)
Max. operating voltage 15 A
Maximum output power: 40 W x 4 channels
Constant output power: 25 W x 4 channels
Operating temperature: –10 to 60 °C
at humidity levels of 45 % to 80 % RH
Storage temperature: –10 to 60 °C
at humidity levels of 30 % to 90 % RH
Dimensions W x H x D: 178 x 101.5 x 169 mm
Weight: Approx. 1.9 kg
FM
Signal/noise ratio: > 55 dB
Sensitivity (S/N = 30dB): 18 dBμV
Frequency range: 87.5 – 108.0 MHz
Frequency response (+3 dB): 20 Hz – 12.5 kHz
Station search sensitivity: 20 dBμV–28 dBμV
Distortion factor: ≤ 1,0 %
Stereo channel separation (1 kHz): ≥ 25 dB
Input impedance: 75 Ω
MW
Sensitivity (S/N = 20dB): 30 dBμV
Selectivity (±9 kHz): ≥ 50 dB
