INSTALLATION
EPT019297 Issue 1 November 2016 3-7
Ax350i/Ax550i
Power
Connector
USB Type A
Ethernet
TouchPanel
Connector
Beacon
Connector
Alarm
Connector
Control
Port
Extended GPIO
(Option not shown)
RS232
GPIO
Powered
HMI
Ax350i/Ax550i External Connections
Product Sensor /
Shaft Encoder
Product Sensor /
Shaft Encoder
