Domino Ax Series User Manual

OPERATION
EPT019297 Issue 1 November 2016 4-23
Forward and Reverse Offset
Forward offset is used to adjust the position of the label on the print surface. If the print head is on
a traversing line the Reverse offset can also be set.
Note: A global offset setting is also available to adjust the offset for all label designs, see
page 4-56.
To adjust the offset for an individual label design:
(1) In the label creator’s side menu, select the Label tab.
(2) Select the Settings menu.
(3) Adjust the Forward offset (mm) or Reverse offset (mm) setting.
(4) Select the Save icon to save the setting.
End of procedure.
Print Offset Diagram
Print Delay Print Delay
Reverse
Offset
Forward
Offset
Direction of printDirection of print
Print
Trigger
Print
Trigger
