Domino Ax Series

INSTALLATION
3-10 EPT019297 Issue 1 November 2016
TouchPanel Type 4
The TouchPanel Type 4 is a user interface with a 7 inch touch screen. The TouchPanel Type 4 has
2 USB ports and a connector to provide control of the Ax350i/Ax550i printers.
TouchPanel to Printer
Connection
USB Type A
TouchPanel Type 4 Connections
TouchPanel Type 4 Front View
