3.9 Quad Box Wiring
4 Boards Power
16.5 VAC, 40 VA Required
18 GA. Wire 100 ft max
16 GA. Wire 200 ft max
Communication
Lines and Power
Terminal
Access Point
Board Terminal
Access Point Board Terminal
To DoorKing
Access Control
System
Access
Point
Board
Terminal
Access
Point
Board
Terminal
#6-Green
#7-White
#8-Black
#9-Red
#10-Red Busy
#27-Black Communication Com
#28-White Communication Data 1
#29-Green Communication Data 0
#17-Blue Relay Input NO
#8-Brown Relay Input Com
#33-16.5 VAC
#34-16.5 VAC
#6-Green Data 0
#7-White Data 1
#8-Black Common
#9-Red 12 VDC
#15-Door Ajar Input
#18-Request to Exit
#26-Output Relay #25-Output Relay
From
Card Reader
Card Reader
Request to Exit
Button
From
Door Lock
#6-Green Data 0
#7-White Data 1
#8-Black Common
#9-Red 12 VDC
#15-Door Ajar Input
#18-Request to Exit
#26-Output Relay #25-Output Relay
From
Card Reader
From
Door Lock
#6-Green Data 0
#7-White Data 1
#8-Black Common
#9-Red 12 VDC
#15-Door Ajar Input
#18-Request to Exit
#26-Output Relay #25-Output Relay
From
Card Reader
From
Door Lock
Sample Included Board Wiring
Each of the boards are wired to their own Access
Point Board Terminal and all are wired to the
Communication Lines and Power Terminal.
Included board MUST be wired to LED on
enclosure door to meet UL 294 compliance.
DO NOT wire to access control system
Magnetic Contact Switch Door Ajar Input
#15-Door
Ajar Input
#18-Request to Exit
#25-Output Relay
#26-Output Relay
#8-Common
#8-Common
EXIT
PUSH TO
Red
Green
Black
White
Magnetic lock
Output Relay:
Normally Closed (NC)
Electric strike
Output Relay:
Normally Open (NO)
Door Lock
Do Not Connect
To A Receptacle
Controlled By A
ON/OFF Switch.
Wire polarity
does not matter.
LED on
Enclosure
Door
Important Note: 115 VAC
convience outlets power
wiring for quad box (section
2.3) is NOT shown.
Important Note: Gate
operator data wiring
(section 3.10) is NOT
shown.
16.5VAC
40 VA
