29
2358-065 Issued 7-19
Version E
4.3 Programming Step Descriptions
Sets the amount of time the door lock will remain unlock after the Output Relay has been activated (Terminals 25 & 26).
Program Step 1: Door Strike Timer
Sets the amount of time the door lock will remain unlock after the Request to Exit has been activated (Input at terminal 18).
Program Step 2: Free Exit Timer, Strike Time
Sets the amount of time the door contact switch (Input at terminal 15) can remain open until terminals 21 & 22 (Aux relay) and
23 & 24 (Alarm relay) will be activated. Timer will start after a valid access and egress has been granted.
Program Step 3: Door Ajar Timer
Sets the amount of time the aux relay will activate terminals 21 & 22. Timer will start after a valid access and egress has been granted.
Program Step 4: Aux Relay Timer
Sets the amount of time the aux relay will activate terminals 21 & 22 upon Request to Exit. This feature can ONLY be used when using
step 12 (Dual Door Mode).
Program Step 5: Free Exit Timer, Aux Relay
Sets how the door contact switch will operate. Normally Open (NO)/Circuit Open (CO) is typically used (Factory default setting of 0).
Normally Closed (NC)/Circuit Closed (CC) can be used if required (set to 1).
Program Step 8: Door Contact Switch Logic
When turned on (set to 1), will relock the door 1 second after door returns to closed position, even if the strike timer has not timed out. The
alarm relay and aux relay will NOT reset after door returns to closed position. A door contact switch is required for this feature. This feature
cannot be used when using step 12 (Dual Mode).
Program Step 9: Auto Relock
Sets how the card reader’s beeper or LED will respond when the door is held open longer than the programmed strike time. When turned on
(set to 1), will activate card reader’s beeper or LED on after strike timer has timed out.
Program Step 10: Beeper / LED Hold Open
When turned on (set to 1), one tracker expansion board will control 2 access points using the board address number that has been physically
set on the tracker expansion board and the next sequential board address number after that. When the access device gets activated from the
physically set tracker expansion board address number and access is granted or denied, the board will then automatically send out the same
access device information to the next sequential board address number to grant or deny access to the second access point. See section 3.8
for wiring.
Program Step 12: Dual Door Mode
When set to 0, Aux relay will NOT function. Alarm relay will “Reset” and if it is set for Integral mode (step 16), it will NOT activate.
If the Alarm relay is set for Bypass mode (step 16), it will activate after the Hold Open (Entry) or Hold Egress (Exit) timer has timed out.
When set to 1, Aux relay will function normally. Alarm relay set for Integral mode (step 16) will NOT activate.
If the Alarm relay is set for Bypass mode (step 16), it will activate after the Hold Open (Entry) or Hold Egress (Exit) timer has timed out.
Program Step 11: Hold Open or Hold Egress Functions
Program Step 6: Not Used
Program Step 7: Not Used
Program Step 13: Not Used
Program Step 14: Not Used
