DoorKing 1830 Series User Manual

28
2358-065 Issued 7-19
Version E
Door Operation Note:
PROPER Condition: The
access control system OR
request to exit device HAS
activated the OUTPUT RELAY
on the tracker expansion board
and the door contact switch is
CLOSED (Door is OPEN). This
indicates that the door has
been PROPERLY OPENED.
FORCED Condition: The
access control system OR
request to exit device has NOT
activated the OUTPUT RELAY
on the tracker expansion board
and the door contact switch is
CLOSED (Door is OPEN). This
indicates that the door has
been FORCED OPENED.
7
8
9
10
11
12
0
1
2
3
4
0 - 12
0 - 4
15
16
17
18
19
20
21
22
23
24
25
26
Aux Relay Functions
Alarm Relay Functions
0:
Disabled
0:
Disabled
Aux Relay as 2nd Alarm Relay. Aux Relay will mirror Alarm Relay functions.
Aux Relay as 2nd Alarm Relay, PULSE. Aux relay will Pulse during any Alarm Relay
activation.
Good Card: Aux Relay will activate for Aux Relay timer for any Access Granted Card
Any Card: Aux Relay will activate for Aux Relay Timer when any card has been
presented.
Bad Card: Aux Relay will activate for Aux Relay timer when a card has been denied
Warn before Hold Open or Release of Hold Open: Aux relay will activate for Aux
Relay timer when scheduled Hold Open begins or ends. Output Relay will be delayed
until Aux Timer expires. Do not set Aux Timer above 60 seconds in this mode.
Sets function for Alarm Relay
Alarm Relay Disabled
Bypass Mode: Alarm Relay provides “Bypass” to Alarm Door Switch. With proper
door input (access or egress) activate Alarm Relay, start Strike timer and Door Ajar
timer. When Door Ajar timer expires, deactivate Alarm Relay.
If second Door Contact Switch is provided, generate transaction for Door Ajar and
Door Closed following Door Forced condition. Also generate transaction for Door
Forced condition.
Integral Mode, Door Ajar Timer: Door Contact Switch connected to Tracker, Alarm
Relay provides connection directly to Alarm System. When door is opened for any
reason, start Door Ajar timer. When Door Ajar timer expires and Door is still OPEN,
activate Alarm Relay. Reset when door closes.
Send Door Ajar and Door Close transactions.
Integral Mode, Proper and Forced condition: Door Contact Switch connected to
Tracker, Alarm Relay provides connection directly to Alarm System. With proper door
input (access or egress) start Strike timer and Door Ajar timer. When Door Ajar
timer expires and Door is still OPEN, activate Alarm Relay. Reset when door closes.
If door is opened without proper condition, activate alarm relay. When door closes
deactivate Alarm Relay. Send Door Ajar, Door Close and Door Forced transactions.
Gate Alarm Function: Alarm Relay will activate for 1 second when tracker board
receives a “Gate Forced” or “Gate Obstructed” transaction from the operator control
board.
See Wireless Programming
E1 - Relay connected to 4-pin terminal pins 1 & 2 is on for more than 5 seconds. Relay 1 in 1830 should be set for 00 seconds (0.25 second strike time)
E2 - Relay connected to 4-pin terminal pins 3 & 4 is on for more than 5 seconds. Relay 2 in 1830 should be set for 00 seconds (0.25 second strike time)
CO - One or more non-paired remotes has been detected but base unit's PAIRED switch is on.
A1 - Board address is invalid for Tracker. Board address is improperly set as 0, 1, 2 or 19.
A2 - Dual Mode - Bad Address, 18 or 19 not allowed.
Error codes on LED Displays for Baseboard and Tracker Board
