Doosan D35C-5 User Manual

Operation Section
-143-
DIAGNOSTIC TROUBLE CODE (DTC) CHART – SORTED BY DTC # (2 of 4)
Description
DTC Set 2
Description
DTC Set 2
SPN-2 FMI-2 SPN-2 FMI-2
DTC 601: Microprocessor failure - FLASH
628 13
DTC 1175: MegaJector voltage supply low
520260 4
DTC 604: Microprocessor failure - RAM
630 12
DTC 1176: MegaJector internal actuator fault
detection
520260 12
DTC 606: Microprocessor failure - COP
629 31
DTC 1177: MegaJector internal circuitry fault
detection
520260 12
DTC 615: Start relay coil open
1321 5
DTC 1178: MegaJector internal comm fault
detection
520260 12
DTC 616: Start relay ground short
1321 4
DTC 1182: Fuel impurity level high
520401 0
DTC 617: Start relay coil short to power
1321 3
DTC 1183: MegaJector autozero / lockoff failure
520803 31
DTC 627: Fuel pump relay coil open
1348 5
DTC 1311: Cylinder 1 misfire detected
1323 11
DTC 628: Fuel-pump high-side open or short to ground
1347 5
DTC 1312: Cylinder 2 misfire detected
1324 11
DTC 628: Fuel pump relay control ground short
1348 4
DTC 1313: Cylinder 3 misfire detected
1325 11
DTC 629: Fuel-pump high-side short to power
1347 6
DTC 1314: Cylinder 4 misfire detected
1326 11
DTC 629: Fuel pump relay coil short to power
1348 3
DTC 1315: Cylinder 5 misfire detected
1327 11
DTC 642: Sensor supply voltage 1 low
1079 4
DTC 1316: Cylinder 6 misfire detected
1328 11
DTC 643: Sensor supply voltage 1 high
1079 3
DTC 1317: Cylinder 7 misfire detected
1329 11
DTC 650: MIL open
1213 5
DTC 1318: Cylinder 8 misfire detected
1330 11
DTC 652: Sensor supply voltage 2 low
1080 4
DTC 1411: EMWT1 voltage high
441 3
DTC 653: Sensor supply voltage 2 high
1080 3
DTC 1412: EMWT2 voltage high
442 3
DTC 685: Power relay coil open
1485 5
DTC 1413: EMWT1 voltage low
441 4
DTC 686: Power relay ground short
1485 4
DTC 1414: EMWT2 voltage low
442 4
DTC 687: Power relay coil short to power
1485 3
DTC 1415: EMWT1 higher than expected stage 1
441 15
DTC 916: Shift actuator feedback out-of-range
520226 3
DTC 1416: EMWT2 higher than expected stage 1
442 15
DTC 919: Shift unable to reach desired gear
520226 7
DTC 1417: EMWT1 higher than expected stage 2
441 0
DTC 920: Shift actuator or drive circuit failed
520226 31
DTC 1418: EMWT2 higher than expected stage 2
442 0
DTC 1111: RPM above fuel rev limit level
515 16
DTC 1419: ERWT1 voltage high
443 3
DTC 1112: RPM above spark rev limit level
515 0
DTC 1420: ERWT2 voltage high
444 3
DTC 1121: FPP1/2 simultaneous voltages out-of-range
(redundanc
91 31
DTC 1421: ERWT1 voltage low
443 4
DTC 1122: FPP1/2 do not match each other or IVS
(redundancy lo
520250 31
DTC 1422: ERWT2 voltage low
444 4
DTC 1131: WGP voltage high
1192 3
DTC 1423: ERWT1 higher than expected stage 1
443 15
DTC 1132: WGP voltage low
1192 4
DTC 1424: ERWT2 higher than expected stage 1
444 15
DTC 1151: Closed-loop LPG high
520206 0
DTC 1425: ERWT1 higher than expected stage 2
443 0
DTC 1152: Closed-loop LPG low
520206 1
DTC 1426: ERWT2 higher than expected stage 2
444 0
DTC 1153: Closed-loop NG high
520207 0
DTC 1511: AUX analog Pull-Up 1 high voltage
520216 3
DTC 1154: Closed-loop NG low
520207 1
DTC 1512: AUX analog Pull-Up 1 low voltage
520216 4
DTC 1155: Closed-loop gasoline bank1 high
520204 0
DTC 1513: AUX analog Pull-Up 2 high voltage
520217 3
DTC 1156: Closed-loop gasoline bank1 low
520204 1
DTC 1514: AUX analog Pull-Up 2 low voltage
520217 4
DTC 1157: Closed-loop gasoline bank2 high
520205 0
DTC 1515: AUX analog Pull-Down 1 high voltage
520215 3
DTC 1158: Closed-loop gasoline bank2 low
520205 1
DTC 1516: AUX analog Pull-Down 1 low voltage
520215 4
DTC 1161: Adaptive-learn LPG high
520202 0
DTC 1517: AUX analog Pull-Up 3 high voltage
520218 3
DTC 1162: Adaptive-learn LPG low
520202 1
DTC 1518: AUX analog Pull-Up 3 low voltage
520218 4
DTC 1163: Adaptive-learn NG high
520203 0
DTC 1521: CHT higher than expected stage 1
110 16
DTC 1164: Adaptive-learn NG low
520203 1
DTC 1522: CHT higher than expected stage 2
110 0
DTC 1165: Catalyst inactive on LPG
520213 10
DTC 1531: Gov1/2/3 interlock failure
520270 31
DTC 1166: Catalyst inactive on NG
520214 10
DTC 1541: AUX analog Pull-Up/Down 1 high
voltage
520219 3
DTC 1171: MegaJector delivery pressure higher than expected
520260 0
DTC 1542: AUX analog Pull-Up/Down 1 low voltage
520219 4
DTC 1172: MegaJector delivery pressure lower than expected
520260 1
DTC 1543: AUX analog Pull-Up/Down 2 high
voltage
520220 3
DTC 1173: MegaJector comm lost
520260 31
DTC 1544: AUX analog Pull-Up/Down 2 low voltage
520220 4
DTC 1174: MegaJector voltage supply high
520260 3
DTC 1545: AUX analog Pull-Up/Down 3 high
voltage
520221 3
