DIAGNOSTIC TROUBLE CODE (DTC) CHART – SORTED BY SPN:FMI (1 of 4)
Description
DTC Set 2
Description
DTC Set 2
SPN-2 FMI-2 SPN-2 FMI-2
DTC 1561: AUX analog Pull-Down 2 high voltage 0 3 DTC 107: MAP voltage low 106 4
DTC 1561: AUX analog Pull-Down 3 high voltage 0 3 DTC 108: MAP pressure high 106 16
DTC 1561: AUX analog Pull-Down 2 low voltage 0 4 DTC 2229: BP pressure high 108 0
DTC 1561: AUX analog Pull-Down 3 low voltage 0 4 DTC 129: BP pressure low 108 1
DTC 1621: RS-485 Rx inactive 0 31 DTC 1522: CHT higher than expected stage 2 110 0
DTC 1622: RS-485 Rx noise 0 31 DTC 217: ECT higher than expected stage 2 110 0
DTC 1623: RS-485 Rx bad packet format 0 31 DTC 118: ECT voltage high 110 3
DTC 1624: RS-485 remote shutdown request 0 31 DTC 117: ECT voltage low 110 4
Undefined DTC - Index 10297 0 31 DTC 116: ECT higher than expected stage 1 110 15
Undefined DTC - Index 10298 0 31 DTC 1521: CHT higher than expected stage 1 110 16
Undefined DTC - Index 10299 0 31 DTC 563: Vbat voltage high 168 15
DTC 2116: FPP2 higher than IVS 29 0 DTC 562: Vbat voltage low 168 17
DTC 2140: FPP2 lower than IVS 29 1 DTC 2428: EGT temperature high 173 0
DTC 2128: FPP2 voltage high 29 3 DTC 183: FT high voltage 174 3
DTC 2127: FPP2 voltage low 29 4 DTC 182: FT low voltage 174 4
DTC 221: TPS1-2 higher than expected 51 0 DTC 1417: EMWT1 higher than expected stage 2 441 0
DTC 121: TPS1-2 lower than expected 51 1 DTC 1411: EMWT1 voltage high 441 3
DTC 123: TPS1 voltage high 51 3 DTC 1413: EMWT1 voltage low 441 4
DTC 122: TPS1 voltage low 51 4 DTC 1415: EMWT1 higher than expected stage 1 441 15
DTC 2112: Unable to reach higher TPS 51 7 DTC 1418: EMWT2 higher than expected stage 2 442 0
DTC 2111: Unable to reach lower TPS 51 7 DTC 1412: EMWT2 voltage high 442 3
DTC 2135: TPS1/2 simultaneous voltages out-of-ran 51 31 DTC 1414: EMWT2 voltage low 442 4
DTC 502: Roadspeed input loss of signal 84 1 DTC 1416: EMWT2 higher than expected stage 1 442 15
DTC 2115: FPP1 higher than IVS 91 0 DTC 1425: ERWT1 higher than expected stage 2 443 0
DTC 2139: FPP1 lower than IVS 91 1 DTC 1419: ERWT1 voltage high 443 3
DTC 1630: J1939 ETC message receipt loss 91 2 DTC 1421: ERWT1 voltage low 443 4
DTC 2122: FPP1 voltage high 91 3 DTC 1423: ERWT1 higher than expected stage 1 443 15
DTC 2123: FPP1 voltage low 91 4 DTC 1426: ERWT2 higher than expected stage 2 444 0
DTC 1651: J1939 ETC message receipt loss while in 91 9 DTC 1420: ERWT2 voltage high 444 3
DTC 2126: FPP1-2 higher than expected 91 16 DTC 1422: ERWT2 voltage low 444 4
DTC 2121: FPP1-2 lower than expected 91 18 DTC 1424: ERWT2 higher than expected stage 1 444 15
DTC 1121: FPP1/2 simultaneous voltages out-of-ran 91 31 DTC 1112: RPM above spark rev limit level 515 0
DTC 88 Fuel pressure higher than expected 94 0
DTC 219: RPM higher than max allowed govern
speed
515 15
DTC 87 Fuel pressure lower than expected 94 1 DTC 1111: RPM above fuel rev limit level 515 16
DTC 92: FP high voltage 94 3 DTC 2130: IVS stuck at-idle, FPP1/2 match 558 5
DTC 91: FP low voltage 94 4 DTC 2131: IVS stuck off-idle, FPP1/2 match 558 6
DTC 521: Oil pressure sender high pressure 100 0 DTC 601: Microprocessor failure - FLASH 628 13
DTC 524: Oil pressure low 100 1 DTC 606: Microprocessor failure - COP 629 31
DTC 524: Oil pressure sender low pressure 100 1 DTC 1612: Microprocessor failure - RTI 1 629 31
DTC 523: Oil pressure sender high voltage 100 3 DTC 1613: Microprocessor failure - RTI 2 629 31
DTC 522: Oil pressure sender low voltage 100 4 DTC 1614: Microprocessor failure - RTI 3 629 31
DTC 520: Oil pressure sender low pressure stage 1 100 18 DTC 1615: Microprocessor failure - A/D 629 31
DTC 127: IAT higher than expected stage 2 105 0 DTC 1616: Microprocessor failure - Interrupt 629 31
DTC 113: IAT voltage high 105 3 DTC 604: Microprocessor failure - RAM 630 12
DTC 112: IAT voltage low 105 4 DTC 336: CRANK input signal noise 636 2
DTC 111: IAT higher than expected stage 1 105 15 DTC 337: Crank signal loss 636 4
