DIAGNOSTIC TROUBLE CODE (DTC) CHART – SORTED BY SPN:FMI (2 of 4)
Description
DTC Set 2
Description
DTC Set 2
SPN-2FMI-2 SPN-2FMI-2
DTC 16: Crank and/or cam could not synchronize du 636 8 DTC 1661: PWM6 open / ground short 925 5
DTC 1629: J1939 TSC1 message receipt loss 639 9 DTC 1664: PWM7 short to power 926 3
DTC 1626: CAN-J1939 Tx fault 639 12 DTC 1663: PWM7 open / ground short 926 5
DTC 1627: CAN-J1939 Rx fault 639 12 DTC 643: Sensor supply voltage 1 high 1079 3
DTC 1628: J1939 CAN address / engine-number con 639 13 DTC 642: Sensor supply voltage 1 low 1079 4
DTC 2619: Tach output short to power 645 3
DTC 1611: Sensor supply voltage 1 and 2
out-of-range
1079 31
DTC 2618: Tach output ground short 645 4 DTC 653: Sensor supply voltage 2 high 1080 3
DTC 261: Injector 1 open or short to ground 651 5 DTC 652: Sensor supply voltage 2 low 1080 4
DTC 262: Injector 1 coil shorted 651 6 DTC 238: TIP high voltage 1127 3
DTC 264: Injector 2 open or short to ground 652 5 DTC 237: TIP low voltage 1127 4
DTC 265: Injector 2 coil shorted 652 6 DTC 1131: WGP voltage high 1192 3
DTC 267: Injector 3 open or short to ground 653 5 DTC 1132: WGP voltage low 1192 4
DTC 268: Injector 3 coil shorted 653 6 DTC 1645: MIL control short to power 1213 3
DTC 270: Injector 4 open or short to ground 654 5 DTC 1644: MIL control ground short 1213 4
DTC 271: Injector 4 coil shorted 654 6 DTC 650: MIL open 1213 5
DTC 273: Injector 5 open or short to ground 655 5 DTC 359: Fuel run-out longer than expected 1239 7
DTC 274: Injector 5 coil shorted 655 6
DTC 2300: Spark coil 1 primary open or short to
ground
1268 5
DTC 276: Injector 6 open or short to ground 656 5 DTC 2301: Spark coil 1 primary shorted 1268 6
DTC 277: Injector 6 coil shorted 656 6
DTC 2303: Spark coil 2 primary open or short to
ground
1269 5
DTC 279: Injector 7 open or short to ground 657 5 DTC 2304: Spark coil 2 primary shorted 1269 6
DTC 280: Injector 7 coil shorted 657 6
DTC 2306: Spark coil 3 primary open or short to
ground
1270 5
DTC 282: Injector 8 open or short to ground 658 5 DTC 2307: Spark coil 3 primary shorted 1270 6
DTC 283: Injector 8 coil shorted 658 6
DTC 2309: Spark coil 4 primary open or short to
ground
1271 5
DTC 285: Injector 9 open or short to ground 659 5 DTC 2310: Spark coil 4 primary shorted 1271 6
DTC 286: Injector 9 coil shorted 659 6
DTC 2312: Spark coil 5 primary open or short to
ground
1272 5
DTC 288: Injector 10 open or short to ground 660 5 DTC 2313: Spark coil 5 primary shorted 1272 6
DTC 289: Injector 10 coil shorted 660 6
DTC 2315: Spark coil 6 primary open or short to
ground 1273
5
DTC 1631: PWM1-Gauge1 open / ground short 697 5 DTC 2316: Spark coil 6 primary shorted 1273 6
DTC 1632: PWM1-Gauge1 short to power 697 6
DTC 2318: Spark coil 7 primary open or short to
ground
1274 5
DTC 1633: PWM2-Gauge2 open / ground short 698 5 DTC 2319: Spark coil 7 primary shorted 1274 6
DTC 1634: PWM2-Gauge2 short to power 698 6
DTC 2321: Spark coil 8 primary open or short to
ground
1275 5
DTC 1635: PWM3-Gauge3 open / ground short 699 5 DTC 2322: Spark coil 8 primary shorted 1275 6
DTC 1636: PWM3-Gauge3 short to power 699 6
DTC 2324: Spark coil 9 primary open or short to
ground
1276 5
DTC 1637: PWM4 open / ground short 700 5 DTC 2325: Spark coil 9 primary shorted 1276 6
DTC 1638: PWM4 short to power 700 6
DTC 2327: Spark coil 10 primary open or short to
ground
1277 5
DTC 1547: AUX analog Pull-Up/Down 4 high voltage 713 3 DTC 2328: Spark coil 10 primary shorted 1277 6
DTC 1548: AUX analog Pull-Up/Down 4 low voltage 713 4 DTC 617: Start relay coil short to power 1321 3
DTC 341: CAM input signal noise 723 2 DTC 616: Start relay ground short 1321 4
DTC 342: Loss of CAM input signal 723 4 DTC 615: Start relay coil open 1321 5
DTC 134: EGO1 open / lazy 724 10 DTC 1311: Cylinder 1 misfire detected 1323 11
DTC 326: Knock1 excessive or erratic signal 731 2
DTC 301: Cylinder 1 emissions/catalyst damaging
misfire
1323 31
DTC 327: Knock1 sensor open or not present 731 4 DTC 1312: Cylinder 2 misfire detected 1324 11
DTC 1643: Buzzer control short to power 920 3
DTC 302: Cylinder 2 emissions/catalyst damaging
misfire
1324 31
DTC 1641: Buzzer control ground short 920 4 DTC 1313: Cylinder 3 misfire detected 1325 11
DTC 1642: Buzzer open 920 5
DTC 303: Cylinder 3 emissions/catalyst damaging
misfire
1325 31
DTC 1662: PWM6 short to power 925 3 DTC 1314: Cylinder 4 misfire detected 1326 11
