Operation Section
-101-
7. To change the lift truck direction of travel, release the
accelerator pedal.
8. Push down on the service brake pedal to reduce the
lift truck speed as necessary.
9. Move the directional lever to the desired direction of
travel. Slowly push down on the accelerator pedal as
the lift truck changes direction.
10. When the direction change is completed, continue to
push down on the accelerator pedal to obtain the
desired travel speed.
11. To stop the lift truck when traveling in either direction,
release the accelerator pedal (1).
12. Push down on the service brake pedal (2) and bring
the lift truck to a smooth stop.
Inching
NOTE: The purpose of the inching pedal is to provide
precise lift truck inching control at very slow
travel speed and high engine rpm. This is used
for fast hydraulic lift, during load approach, pick
up or load positioning.
1. To inch (creep) in either direction, slowly push down
on the inching pedal. This will start to apply the service
brakes and allow the transmission clutch discs to slip.
2. Vary the position of the inching pedal and the
accelerator pedal to control the inching speed and
distance.
3. Pushing down further on the inching pedal will
disengage the transmission completely and apply the
service brakes fully to stop and hold the lift truck. This
will provide full engine power for fast hydraulic lift.
4. Avoid overuse of the inching pedal as this may cause
the automatic transmission oil to overheat or the
clutch to slip. Do not use as a footrest or for long
periods of time.
5. If user operates continuously pushing work or both
brake pedal and accelerator pedal were depressed at
the same time, it may cause the automatic
transmission oil to overheat or the clutch to slip.
