General Section
-32-
Specifications
CHARACTERISTICS
1.2 Model designation D35S-9 D40S-9
1.3 Drive: Diesel, Gasoline, LP Diesel Diesel
1.4
Operator type: Hand, Pedestrian, Standing, Seated,
Order-picker
Seated Seated
1.5
Load Capacity Q
kg (lb) 3,500 (8,000) 4,000 (9,000)
1.6 Load center C mm (in) 600 (24) 600 (24)
1.8
Load Distance: Center of Driveaxle to fork x
mm (in) 560 (22) 560 (22)
1.9
Wheelbase y
mm (in) 2,015 (79.5) 2,015 (79.5)
WEIGHT
32 Service weight
kg (lb)
5,795 (12,775) 6,100 (13,450)
33 Axle Loading, Laden Front/Rear
kg (lb)
8,390 / 905
(18,495 / 1,995)
9,115 / 985
(20,095 / 2,170)
34 Axle Loading, Unladen Front/Rear
kg (lb)
2,255 / 3,540
(4,970 / 7,805)
2,425 / 3,675
(5,345 / 8,105)
TYRES
3.1
Tyres: pneumatic (P), superelastic (SE), cushion (C)
P P
3.2
Tyre size, Front
8.25 x 15-14PR/
7.50 x 16-12PR
300 x 15-18PR/
7.50 x 16-12PR
3.3
Tyre size, Rear
7.00 x 12-12PR 7.00 x 12-12PR
3.5
Wheels, number Front/Rear (x = driven wheels)
x 2/2 x 2/2
3.6 Tread, Front
b
11 mm (in)
1,140 / 1,290 (44.9 / 50.8) 1,155 / 1,290 (45.5 / 50.8)
3.7 Tread, Rear
b
12 mm (in)
1,115 (43.9) 1,115 (43.9)
DIMENSIONS
4.1 Tilt of Mast/Fork carriage Forward/Backward α/β
°
8 / 10 8 / 10
4.2 Height, Mast lowered h
1 mm (in)
2,225 (87.6) 2,230 (87.8)
4.3 Free Lift h
2 mm (in)
160 (6.3) 160 (6.3)
4.4 Lift h
3
mm (in) 3,000 (118.1) 3,000 (118.1)
4.5 Height, Mast Extended h
4 mm (in)
4,265 (167.9) 4,270 (168.1)
4.7 Height of Overhead Guard (Cabin) h
6
mm (in) 2,225 (87.6) 2,230 (87.8)
4.8 Height of Seat h
7 mm (in)
1,220 (48.0) 1,225 (48.2)
4.19 Overall Length l
1
mm (in)
4,160 (163.8) 4,200 (165.4)
4.20 Length to Forkface l
2
mm (in)
2,99 5(116.3) 3,000 (118.1)
4.21 Overall Width
b
1
/b
2
mm (in)
1,370 (53.9) 1,455 (57.3)
4.22 Fork Dimensions
s/e/l
mm (in)
50 x 150 x 1,050
(2.0 x 5.9 x 41.3)
50 x 150 x 1,050
(2.0 x 5.9 x 41.3)
4.23 Fork carriage ISO 2328, class/type A,B
Ⅲ Ⅲ
4.24 Fork carriage width b
3 mm (in)
1,250 (49.2) 1,250 (49.2)
4.31 Ground Clearance, laden, below mast m
1 mm (in)
150 (5.9) 160 (6.3)
4.32 Ground Clearance, center of wheelbase m
2 mm (in)
205 (8.1) 205 (8.1)
4.34.1 Aisle width for pallets 1,000 x 1,200 crossways A
st mm (in)
4,515 (177.8) 4,560 (179.5)
4.34.2 Aisle width for pallets 800 x 1,200 crossways A
st mm (in)
4,715 (185.6) 4,760 (187.4)
4.35 Turning Radius W
a
mm (in)
2,755 (108.5) 2,800 (110.2)
4.36 Internal Turning Radius b
13 mm (in)
805 (31.7) 805 (31.7)
PERFORMANCE DATA
5.1
Travel Speed, Laden/Unladen km/h (mph)
24/26 (15/16) 24/26 (15 / 16)
5.2
Lift Speed, Laden/Unladen m/s (fpm)
0.56/0.60 (109/117) 0.55/0.60 (107/117)
5.3
Lowering Speed, Laden/Unladen m/s (fpm)
0.45/0.50 (88.5 / 98.4) 0.45/0.50 (88.5 / 98.4)
5.5
Drawbar pull, Laden/Unladen (@ 1.6 km/h) N (lb)
34,075 (7,660) 33,540/- (7,540)
5.6 Max. Drawbar pull, Laden/Unladen N (lb) 37,498 (8,430) 36,894/- (8,295)
5.7
Gradeability, Laden/Unladen (@ 1.6 km/h) %
38.5 34.5
5.8 Max. Gradeability, Laden/Unladen % 43 38.5
5.10
Service Brake
Foot/Hyd Foot/Hyd
