Maintenance Section
-149-
When the oil temperature is 40°C approximately, the cold
side mark on the dipstick is applicable. When the oil
temperature is 80°C approximately, the hot side mark on
the dipstick is applicable.
14. Check for oil leaks at the filter and drain plug.
15. Stop the engine.
16. Select Menu - Vehicle - TCU - "Auto clutch
calibration" in the display.
17. Check that transmission oil temperature is between
40 ~ 90 degree Celsius. If the temperature is too low,
warm up the transmission. In reverse, if the
temperature is too high, cool down the transmission.
18. When the parking brake is ON and the gear is in
neutral, the color of "start" button is changed to blue.
19. With the service brake pedal depressed, click Start
button. Then, calibration will be automatically
conducted. It would take about 2 minutes.
WARNING
While conducting the calibration, make sure to keep
engaging the service brake thoroughly until being
finished. Otherwise, the vehicle may be moved and
this would cause some damage or injury.
20. Select Menu - Vehicle - TCU - "Auto inching
calibration" in the display.
21. Make sure if the inching pedal is not depressed.
22. When the parking brake is ON and the gear is in
neutral, the color of "start" button is changed to blue.
23. Click the start button then, the calibration will be
conducted automatically. It would take about (2)
seconds.
NOTICE
Do not press the inching pedal during calibration.
