General Section
-34-
Specifications
CHARACTERISTICS
1.2 Model designation D45S-9
D50C-9
D55C-9
1.3 Drive: Diesel, Gasoline, LP
Diesel Diesel Diesel
1.4
Operator type: Hand, Pedestrian, Standing, Seated,
Order-picker
Seated Seated Seated
1.5
Load Capacity Q
kg (lb)
4,500 (10,000) 5,000 (11.000) 5,500 (12,000)
1.6 Load center C mm (in)
600 (24) 600 (24) 600 (24)
1.8
Load Distance: Center of Driveaxle to fork x
mm (in)
560 (22) 570(22.5) 570 (22.5)
1.9
Wheelbase y
mm (in)
2,115 (83.3) 2,115 (83.3 ) 2,115 (83.3 )
WEIGHT
32 Service weight
kg (lb)
6,530 (14,395) 6,930 (15,280) 7,300 (16,095)
33 Axle Loading, Laden Front/Rear
kg (lb)
9,960 / 1,070
(21,960 / 2,360)
10,770 / 1,160
(23,745 / 2,555)
11,565 / 1,235
(25,495 / 2,720)
34 Axle Loading, Unladen Front/Rear
kg (lb)
2,630 / 3,900
(5,800 / 8,595)
2,655 / 4,275
(5,855 / 9,524)
2,705 / 4,595
(5,965 / 10,130)
TYRES
3.1
Tyres: pneumatic (P), superelastic (SE), cushion (C)
P P P
3.2
Tyre size, Front
300 x 15-18PR/
7.50 x 16-12PR
300 x 15-18PR/
7.50 x 16-12PR
300 x 15-18PR/
7.50 x 16-12PR
3.3
Tyre size, Rear
7.00 x 12-12PR 7.00 x 12-14PR 7.00 x 12-14PR
3.5
Wheels, number Front/Rear (x = driven wheels)
x 2/2 x 2/2 x 2/2
3.6 Tread, Front
b
11
mm (in)
1,155 / 1,290
(45.5 / 50.8)
1,155 / 1,290
(45.5 / 50.8)
1,155 / 1,290
(45.5 / 50.8)
3.7 Tread, Rear
b
12
mm (in)
1,115 (43.9) 1,115 (43.9) 1,115 (43.9)
DIMENSIONS
4.1 Tilt of Mast/Fork carriage Forward/Backward
α/β
°
8 / 10 8 / 10 8 / 10
4.2 Height, Mast lowered h
1
mm (in) 2,230 (87.8) 2,230(87.8) 2,230 (87.8)
4.3 Free Lift h
2 mm (in)
160 (6.3) 170 (6.7) 170 (6.7)
4.4 Lift h
3
mm (in) 3,000 (118.1) 3,050 (120) 3,050 (120)
4.5 Height, Mast Extended h
4 mm (in)
4,420 (174.0) 4,470 (176.0) 4,470 (176.0)
4.7 Height of Overhead Guard (Cabin) h
6 mm (in)
2,230 (87.8) 2,230 (87.8) 2,230 (87.8)
4.8 Height of Seat h
7 mm (in)
1,225 (48.2) 1,225 (48.2) 1,225 (48.2)
4.19 Overall Length l
1
mm (in)
4,480 (176.4) 4,530 (178.4) 4,560 (179.5)
4.20 Length to Forkface l
2
mm (in)
3,260 (128.4) 3,300 (129.9) 3,340 (131.5)
4.21 Overall Width
b
1
/b
2
mm (in)
1,455 (57.3) 1,455 (57.3) 1,455 (57.3)
4.22 Fork Dimensions
s/e/l
mm (in)
50 x 150 x 1,200
(2.0 x 5.9 x 47.2)
50 x 150 x 1,200
(2.0 x 5.9 x 47.2)
50 x 150 x 1,200
(2.0 x 5.9 x 47.2)
4.23 Fork carriage ISO 2328, class/type A,B
IV IV IV
4.24 Fork carriage width b
3 mm (in)
1,330 (52.4) 1,330 (52.4) 1,330 (52.4)
4.31 Ground Clearance, laden, below mast m
1
mm (in)
160 (6.3) 160 (6.3) 160 (6.3)
4.32 Ground Clearance, center of wheelbase m
2 mm (in)
205 (8.1) 205 (8.1) 205 (8.1)
4.34.1
Aisle width for pallets 1,000 x 1,200 crossways A
st mm (in)
4,610 (181.5) 4,640 (182.7) 4,670 (183.9 )
4.34.2
Aisle width for pallets 800 x 1,200 crossways A
st
mm (in)
4,810 (189.4) 4,840 (190.6) 4,870 (191.7)
4.35 Turning Radius W
a mm (in)
2,850 (112.2) 2,870 (113.0) 2,900 (114.2)
4.36 Internal Turning Radius b
13
mm (in)
820 (32.3) 820 (32.3) 820 (32.3)
PERFORMANCE DATA
5.1
Travel Speed, Laden/Unladen
km/h
(mph)
24 / 26 (15 / 16) 24 / 26 (15 / 16) 24 / 26 (15 / 16)
5.2
Lift Speed, Laden/Unladen
m/s
(fpm)
0.54 / 0.60
(105 / 117)
0.53 / 0.60
(103 / 117)
0.52 / 0.60
(101 / 117)
5.3
Lowering Speed, Laden/Unladen
m/s
(fpm)
0.45 / 0.50
(88.5 / 98.4)
0.45 / 0.50
(88.5 / 98.4)
0.45 / 0.50
(88.5 / 98.4)
5.5
Drawbar pull, Laden/Unladen (@ 1.6 km/h) N (lb)
33,564 (7,545 /-) 33,390 (7,505) 33,170 (7,455)
5.6
Max. Drawbar pull, Laden/Unladen N (lb)
36,970 (8,310/-) 36,816 (8,275) 36,595 (8,225)
5.7
Gradeability, Laden/Unladen (@ 1.6 km/h) %
31.5 28.5 26
5.8
Max. Gradeability, Laden/Unladen %
35 31.5 29
5.10
Service Brake
Foot/Hyd Foot/Hyd Foot/Hyd
