General Section
-36-
Specifications
CHARACTERISTICS
1.2 Model designation D40SC-9 D45SC-9
1.3 Drive: Diesel, Gasoline, LP
Diesel Diesel
1.4
Operator type: Hand, Pedestrian, Standing, Seated,
Order-picker
Seated Seated
1.5 Load Capacity Q kg (lb)
4,500 (10,000) 5,500 (12,000)
1.6
Load center C
mm (in)
500 (19.7) 500 (19.7)
1.8
Load Distance: Center of Driveaxle to fork x
mm (in)
560 (22) 570 (22.5)
1.9
Wheelbase y
mm (in)
2,015( 79.5) 2,115 (83.3)
WEIGHT
2.1 Service weight
kg (lb)
5,795 (12,775) 6,100 (13,450)
2.2 Axle Loading, Laden Front / Rear
kg (lb)
8,390 / 905
(18,495 / 1,995)
9,115 / 985
(20,095 / 2,170)
2.3 Axle Loading, Unladen Front / Rear
kg (lb)
2,255 / 3,540
(4,970 / 7,805)
2,425 / 3,675
(5,345 / 8,105)
TYRES
3.1
Tyres: pneumatic (P), superelastic (SE), cushion (C) P P
3.2 Tyre size, Front
8.25 x 15-14PR/
7.50 x 16-12PR
300 x 15-18PR/
7.50 x 16-12PR
3.3 Tyre size, Rear
7.00 x 12-12PR 7.00 x 12-12PR
3.5 Wheels, number Front / Rear (x = driven wheels)
x 2/2 x 2/2
3.6
Tread, Front
b
11
mm (in)
1,140 / 1,290 (44.9 / 50.8) 1,155 / 1,290 (45.5 / 50.8)
3.7
Tread, Rear
b
12
mm (in)
1,115 (43.9) 1,115 (43.9)
PERFORMANCE
4.1
Tilt of Mast /Fork carriage Forward/Backward
α/β
°
8 / 10 8 / 10
4.2
Height, Mast lowered h
1 mm (in)
2,225 (87.6) 2,230 (87.8)
4.3
Free Lift h
2 mm (in)
160 (6.3) 160 (6.3)
4.4
Lift h
3 mm (in)
3,000 (118.1) 3,000 (118.1)
4.5
Height, Mast Extended h
4
mm (in)
4,265 (167.9) 4,270 (168.1)
4.7
Height of Overhead Guard (Cabin) h
6 mm (in)
2,225 (87.6) 2,230 (87.8)
4.8
Height of Seat h
7
mm (in)
1,220 (48.0) 1,225 (48.2)
4.19
Overall Length l
1
mm (in)
4,160 (163.8) 4,20 0 (165.4)
4.20
Length to Forkface l
2
mm (in)
2,995 (116.3) 3,000 (118. )
4.21
Overall Width
b
1
/b
2
mm (in)
1,370 (53.9) 1,455 (57.3)
4.22
Fork Dimensions
s/e/l
mm (in)
50 x 150 x 1,050
2.0 x 5.9 x 41.3
50 x 150 x 1,050
2.0 x 5.9 x 41.3
4.23
Fork carriage ISO 2328, class / type A,B
Ⅲ Ⅲ
4.24
Fork carriage width b
3 mm (in)
1,250 (49.2) 1,250 (49.2)
4.31 Ground Clearance, laden, below mast m
1
mm (in) 150 (5.9) 160 (6.3)
4.32
Ground Clearance, center of wheelbase m
2 mm (in)
205 (8.1) 205 (8.1)
4.34.1 Aisle width for pallets 1,000 x 1,200 crossways A
st
mm (in) 4,515 (177.8) 4,560 (179.5)
4.34.2
Aisle width for pallets 800 x 1,200 crossways A
st mm (in)
4,715 (185.6) 4,760 (187.4)
4.35
Turning Radius W
a mm (in)
2,755 (108.5) 2,800 (110.2)
4.36
Internal Turning Radius b
13 mm (in)
805 (31.7) 805 (31.7)
PERFORMANCE DATA
5.1 Travel Speed, Laden / Unladen
km/h
(mph)
24 / 26 (15 / 16) 24 / 26 (15 / 16)
5.2 Lift Speed, Laden / Unladen m/s (fpm)
0.56 / 0.60 (109/117) 0.55 / 0.60 (107 / 117)
5.3 Lowering Speed, Laden / Unladen m/s (fpm)
0.45 / 0.50 (88.5 / 98.4) 0.45 / 0.50 (88.5 / 98.4)
5.5 Drawbar pull, Laden / Unladen (@ 1.6 km/h) n (lb)
34,075 (7,660) 33,540 (7,540)
5.6 Max. Drawbar pull, Laden / Unladen v (lb)
37,498 (8,430) 36,894 (8,295)
5.7 Gradeability, Laden / Unladen (@ 1.6 km/h) %
38.5 34.5
5.8 Max. Gradeability, Laden / Unladen %
43 38.5
5.10 Service Brake
Foot / Hyd Foot / Hyd
