General Section
-38-
Specifications
CHARACTERISTICS
1.2 Model designation
D50SC-9
D55SC-9
1.3 Drive: Diesel, Gasoline, LP
Diesel Diesel
1.4
Operator type: Hand, Pedestrian, Standing, Seated,
Order-picker
Seated Seated
1.5 Load Capacity Q kg (lb)
5,000 (11.000) 5,500 (12,000)
1.6
Load center C
mm (in)
500 (19.7) 500 (19.7)
1.8
Load Distance: Center of Driveaxle to fork x
mm (in)
560 (22) 570 (22.5)
1.9
Wheelbase y
mm (in)
2,115 (83.3) 2,115 (83.3)
WEIGHT
2.1 Service weight
kg (lb) 6,530 (14,395) 6,930 (15,280)
2.2 Axle Loading, Laden Front / Rear
kg (lb)
9,960 / 1,070
(21,960 / 2,360)
10,770 / 1,160
(23,745 / 2,555)
2.3 Axle Loading, Unladen Front / Rear kg (lb)
2,630 / 3,900
(5,800 / 8,595)
2,655 / 4,275
(5,855 / 9,524)
TYRES
3.1
Tyres: pneumatic (P), superelastic (SE), cushion (C) P P
3.2 Tyre size, Front
300 x 15-18PR
/7.50 x 16-12PR
300 x 15-18PR/
7.50 x 16-12PR
3.3 Tyre size, Rear
7.00 x 12-12PR 7.00 x 12-14PR
3.5 Wheels, number Front / Rear (x = driven wheels)
x 2/2 x 2/2
3.6 Tread, Front b
11
mm (in) 1,155 / 1,290 (45.5 / 50.8) 1,155 / 1,290 (45.5 / 50.8)
3.7
Tread, Rear
b
12
mm (in)
1,115 (43.9) 1,115 (43.9)
PERFORMANCE
4.1
Tilt of Mast /Fork carriage Forward/Backward
α/β
°
8 / 10 8 / 10
4.2
Height, Mast lowered h
1 mm (in)
2,230 (87.8) 2,230 (87.8)
4.3
Free Lift h
2 mm (in)
160 (6.3) 170 (6.7)
4.4
Lift h
3 mm (in)
3,000 (118.1) 3,050 (120)
4.5
Height, Mast Extended h
4 mm (in)
4,420 (174.0) 4,470 (176.0)
4.7
Height of Overhead Guard (Cabin) h
6 mm (in)
2,230 (87.8) 2,230 (87.8)
4.8
Height of Seat h
7 mm (in)
1,225 (48.2) 1,225(48.2)
4.19
Overall Length l
1
mm (in)
4,480 (176.4) 4,530 (178.4)
4.20
Length to Forkface l
2
mm (in)
3,260 (128.4) 3,300 (129.9)
4.21
Overall Width
b
1
/b
2
mm (in)
1,455 (57.3) 1,455 (57.3)
4.22
Fork Dimensions
s/e/l
mm (in)
50 x 150 x 1,200
(2.0 x 5.9 x 47.2)
50 x 150 x 1,200
(2.0 x 5.9 x 47.2)
4.23
Fork carriage ISO 2328, class / type A,B IV IV
4.24
Fork carriage width b
3
mm (in)
1,330 (52.4) 1,330 (52.4)
4.31
Ground Clearance, laden, below mast m
1 mm (in)
160 (6.3) 160 (6.3)
4.32
Ground Clearance, center of wheelbase m
2
mm (in)
205 (8.1) 205 (8.1)
4.34.1
Aisle width for pallets 1,000 x 1,200 crossways A
st mm (in)
4,610 (181.5) 4,640 (182.7)
4.34.2
Aisle width for pallets 800 x 1,200 crossways A
st mm (in)
4,810 (189.4) 4,840 (190.6)
4.35 Turning Radius W
a
mm (in) 2,850 (112.2 ) 2,870 (113.0 )
4.36
Internal Turning Radius b
13 mm (in)
820 (32.3) 820 (32.3)
PERFORMANCE DATA
5.1 Travel Speed, Laden / Unladen
km/h
(mph)
24 / 26 (15 / 16) 24 / 26 (15 / 16)
5.2 Lift Speed, Laden / Unladen m/s (fpm)
0.54 / 0.60 (105 / 117) 0.53 / 0.60 (103 / 117)
5.3 Lowering Speed, Laden / Unladen m/s (fpm)
0.45
/
0.50
(88.5 / 98.4)
0.45
/
0.50
(88.5 / 98.4)
5.5 Drawbar pull, Laden / Unladen (@ 1.6 km/h) n (lb)
33,564 (7,545) 33,390 (7,505)
5.6 Max. Drawbar pull, Laden / Unladen v (lb)
36,970 (8,310) 36,816 (8,275 )
5.7 Gradeability, Laden / Unladen (@ 1.6 km/h) %
31.5 28.5
5.8 Max. Gradeability, Laden / Unladen %
35 31.5
5.10 Service Brake
Foot / Hyd Foot / Hyd
