G643(E) Service Manual Chapter 6. LPG FUEL DELIVERY SYSTEM 218
Parts Description
CA100 Mixer for G643 Engine
Refer to Figure 45 exploded view on facing page.
REF NO. DESCRIPTION QTY
1 Screws 10-24 x 5/8” T-25 Button Head SEMS 4
2 Mixer Cover 1
3 Mixer Spring 1
4 Diaphragm 1
5 Gas Valve Cone (part of air valve assembly) 1
6 Mixer 1
7 Throttle Body Gasket 1
8 Screws 12-24 x 5/8” Fillister Head SEMS 8
9 Air Horn Adapter 1
10 Air Horn Gasket 1
Parts List for CA100 Mixer
