DORMA CS 80 MAGNEO
26
6mm
Insert the door panel into the door panel
suspension, align it so that it is parallel to
the wall and screw it down.
Move the end stop to the end of the channel.
Place the door panel inside the door frame.
As the door panel is wider than the doorway,
you will have to tilt it.
The end stop must not fall out of the
operator.
As it will be difficult to get hold of the
door panel with in-wall mounting, you
should use wooden wedges to help you
to lift the door panel.
Align the door panel with the aid of the
adjustment nuts so that it is level.
The distance between the bottom edge
of the door panel and the floor should
amount to 6 mm, however, it must not
exceed 8 mm.
