dormakaba USA Inc. System User Guide 7040.0320 | 7
Battery box, alarm
box, or AC adaptor
LA GARD Prgm Cable
LA GARD Keypad
Figure 2 – Multi-Lock System
Battery box, alarm
box, or AC adaptor
LA GARD Prgm Cable
LA GARD Keypad
Lock #1
Multiplexor
2.1 Safe Lock Hardware
Consult each component’s individual documentation for proper mounting, connectivity and installation. The safe itself must be
appropriate for the lock hardware to provide maximum security; certain makes and models of safes may not be appropriate for this
LA GARD safe lock system. If unsure, consult with dormakaba USA Inc. Sales or Support for further information.
