Dr.HD D15 - 5 How to Connect

84
5. How to Connect
D15 - When Connecting the Receiver to a TV
1. Connect the TV antenna to TV ANT IN
2. Connect the Video and Audio of the TV to Video and Audio: connect the red and white
connectors to Audio R and Audio L, and the yellow connector to Video
3. Connect your satellite dish
Video
Audio
HDMI
TV
Satellite Dish
L
R
