Operation – Part 1
20.08.2012 Page 28 of 42 Rev. 04
4.8 Printer settings
The DPU 414 printer provided for use with the equipment has several connection
options.
To set/program the printer for use with the SUPER GL easy / easy+ the following
steps are needed:
1. When switching on the printer keep the “on line” button pressed. You will
then receive a printout of the current settings.
2. Press “on line” again and you can reprogram the printer.
3. Press “on line” for “ON”, press “Feed” for “OFF”
4. Press “Feed” to confirm at the end of the programming process
The following settings are needed for the SUPER GL easy / easy+:
Position SW1 SW2 SW3
1 OFF ON ON
2 ON ON ON
3 ON OFF ON
4 OFF ON ON
5 ON ON OFF
6 OFF ON ON
7 ON ON ON
8 ON OFF ON
4.7 Switch off equipment
The equipment should not be switched off until it is no longer performing any
functions. The equipment should NEVER be switched off in the middle of a
measurement process, during calibration or rinsing, as this can lead to faulty
functioning.
If the equipment is to remain switched off for a long period (e.g. during
holidays), it should be rinsed and emptied before switching off in order to
prevent the liquid in the tubing system from drying. The consumable material
(especially the sensor and calibrator) must also be suitably stored (see Ch.
6.3.6).
Please contact the service department if you have any further questions.
