Maintenance and troubleshooting
20.08.2012 Page 39 of 42 Rev. 04
Please note for installing the pump head (is situated under the sensor – fig. 6.4)
that rounded side of the pump head is shown to the door and the flat side is
shown to the black panel. If you install the pump head you have to hear a Click
and after installing you should not remove it from the axle.
If you remove the pump head you have to press gently the springs at the sides
(fig. 6.5). If you have done this you could remove the pump head pulling it to
the front side of the instrument.
If there are any questions, please call our service for help.
6.3.5 Taking equipment out of operation
To take the analyser out of operation for a long period or to prepare it for
transport, proceed as follows:
1. Rinse the analyser with distilled water (menu item “Emptying”)
2. Empty the system by taking the tube out of the containerkit and selecting
again "Empty"
3. Switch the analyser off and remove all connections
The consumable material (especially the sensor and calibrator) must also be
suitably stored.
Please contact the service department if you have any further questions.
Taking the analyser permanently out of operation:
For disposal of equipment please ask your sales partner.
6.3.7 Prepare equipment for transport
To prepare the analyser for transport, proceed as follows:
- Rinse and empty system (see Ch. 6/3/6)
- Switch off analyser
- Remove containerkit from analyser and remove all reaction cups from the
analyser
- Remove plug from power supply unit and printer and/or EDP
- Disinfect outside of analyser
- Pack and transport the equipment in the original cardboard box with foam
insert only as this is the only way to avoid damage during transport as far
as possible.
 Place analyser in one half of the foam, making sure that the analyser is
placed correctly in the mould
 2. Place the other half of the foam on top and close the carton
 NB. If force is needed to close the transport crate, the analyser is not
correctly seated in the mould.
Please contact your sales partner or the manufacturer is you have any further
questions.
