30 16.50 PRO DR
®
RAPID-FEED™ CHIPPER
s
the
Tools and Supplies needed:
• Clean cloth
• 5/32" Allen Wrench
• Loctite
®
243
and
e Belt” in this Chapter).
2. Wipe all dirt, etc., from the gs with a clean
cloth
3. Apply no more than three pumps of quality general-
purpose lithium grease with a hand-pumped grease
gun to each Bearing Grease Fitting, one on either side
of the Chipper Assembly.
4. Check the Set Screws for tightness. If they are not tight
they should be removed, apply Loctite
®
to the threads,
then reinstall and tighten the Set Screws.
5. Replac .
Grease Fitting
Your RAPID-FEED CHIPPER was greased at the Factory. The operator needs to periodically lubricate
two Bearings of the Chipper Assembly.
SHUT DOWN THE ENGINE, WAIT FOR ALL MOVING PARTS TO COME TO A COMPLETE STOP, REMOVE
SPARK PLUG WIRE, DISCONNECT THE NEGATIVE BATTERY CABLE, THEN WAIT 5 MINUTES BE
• Flexible hose grease gun
• Lithium grease
1. Remove the Belt Cover (see “Removing, Replacing
Adjusting the Driv
grease fittin
(Figure 24).
e the Belt Guard
FORE
PERFORMING ANY MAINTENANCE PROCEDURE OR INSPECTION ON THE CHIPPER.
Bearing
Set
Screw
Grease
Fitting
Bearing
Fitting
Set
w
Front Chipper Bearing
Grease
Scre
OVER LUBRICATION N DAMAGE T E BEARINGS CA H .
Rear Chipper Bearing (under Belt Cover)
Figure 24
