2 16.50 PRO DR
®
RAPID-FEED™ CHIPPER
Specifications
MECHANICAL
SPECIFICATIONS
Engine........................................ Briggs & Stratton
Series.................................... 1650
Oil Capacity .......................... 28 oz.
Fuel Tank Capacity............... 4 Quarts
Chipping Capacity..................... 4.5" Diameter
Wheel Size................................. 5.30/4.50-6 Pneu. (standard non-highway): 4.80/4.00-8 Pneu. (optional Road-
Towing Package only)
Axle ............................................ 3/4" Round Axle (standard non-highway): 1" Spindles Welded to 2" X 2" X 1/4"
Angle (optional Road-Towing Package only)
Number of Chipper Knives....... 1
Chipper Knife Size..................... 6-1/4" X 2" X 3/8"
Chipper Knife Material.............. Heat Treated Tool Steel
Adjustable Knife Wear Plate ..... Yes
Chipper Flywheel....................... 16-1/2" Dia. X 3/4" Thick
Flywheel Weight ........................ 55 Lbs
Chipper Knife Tip Speed ........... 118 mph
Hopper Material........................ 7 GA Neck, 14 GA Hopper
Frame Material.......................... 10 GA Steel
Hopper Opening at Top ........... 22-1/2" x 29"
Machine Weight........................ 372 Lbs (manual-start), 392 Lbs (electric-start)
SHIPPING
SPECIFICATIONS
Shipping Dimensions ............... 48" W x 67" L x 38" H
Shipping Weight........................ 505 Lbs. (electric start w/ Tow Hitch)
Serial Number
A Serial Number is used to identify your machine. The number is located on the Serial Number Label on
your machine. For your convenience and ready reference, enter the Serial Number in the space provided
on the front cover of this manual.
Order Number
An Order Number is used to check and maintain your order history. The number is located on the
upper left portion of your packing slip. For your convenience and ready reference, enter the Order
Number in the space provided on the front cover of this manual.
