Dräger REGARD - Set Over-Range Fault Level; Set Alarm Hysteresis

REGARD 8-Input 4-20 Module & 8-Channel Display Card (ATEX Version)
Issue 2. October 2011
30
Set over-range fault level
Enables a signal above 20mA to trip the fault alarm. The over-range fault level can be set
to 20.5mA to 23.5mA in 0.1mA steps, or set to OFF.
To ensure that a short circuit between 24V and the 4-20mA signal from the
transmitter indicates a fault, as required by EN 60079-29-1, do not set to OFF.
PRESS DISPLAY
• Select command 10–8
  R
FLT O/R
Display shows current setting of head 1: e.g.
h1:OFF
• Select head to change. Current setting shown.
 
h2:21.5
• Select setting for head, e.g. 23mA
 
h2:23.0
• Select next head to change. Current setting shown.
 
h3:OFF
Repeat for other heads
• Confirm selection and exit command
R
10–8:h4
Set alarm hysteresis
Alarm hysteresis can be set from 0 to 5% of FSD in 0.5% steps.
PRESS DISPLAY
• Select command 11–0
  R
HYST
Display shows current setting of head 1: e.g.
h1:1.0%
• Select head to change. Current setting shown.
 
h2:1.0%
• Select setting for head, e.g. 1.5%
 
h2:1.5%
• Select next head to change. Current setting shown.
 
h3:1.0%
Repeat for other heads
• Confirm selection and exit command
R
11–0
