Dräger REGARD - Set Leds to Display Master Alarms or Per Head Alarms; Display Head Number or Channel Number

REGARD 8-Input 4-20 Module & 8-Channel Display Card (ATEX Version)
Issue 2. October 2011
32
Set LEDs to display master alarms or per head alarms
A1 and A2 LEDs may indicate alarm status of each head or the common status of all
active heads.
PRESS DISPLAY
• Select command 60–2
  R
LEDs
Display shows current setting, e.g.
COMMON
COMMON : LEDs indicate alarms for all heads
EACH I/P : LEDs indicate alarms for head currently
displayed
• Select setting required, e.g.
 
EACH I/P
• Confirm selection and exit command
R
60–2
Display head number or channel number
PRESS DISPLAY
• Select command 60–3
  R
HEAD NUM
Display shows current setting, e.g.
HEAD h
_
CHAN
__
: Display channel number.
HEAD h
_
: Display head number.
• Select setting required, e.g. display channel number
 
CHAN
__
• Confirm selection and exit command
R
60–3
Note: the head number is still displayed if no channel number has been set for that
head (i.e. channel number is 0).
