Dräger REGARD - Configuration Saving and Basic Settings

REGARD 8-Input 4-20 Module & 8-Channel Display Card (ATEX Version)
Issue 2. October 2011
19
Save configuration settings
PRESS DISPLAY
• Select command 00–2
  R
SAVE
Asking for confirmation to save settings
SAVE:NO
If no settings have been changed, display shows:
SAVE:NO!
• Select YES
 
SAVE:YES
• Confirm action…
R
WAIT
…confirmation that settings have been saved…
SAVED:OK
…command exits
00–2
Locking card in command mode
Display card automatically exits command mode if no buttons are pressed for 10 minutes.
To prevent card from automatically exiting command mode, use command
60–0.
PRESS DISPLAY
• Select command 60–0
  R
CMD LOCK
NO
• Select YES to lock in command mode
 
YES
• Confirm selection and exit command
R
LOCKED
60–0
Quit command mode
PRESS DISPLAY
• Select command 00–0
  R
QUIT:NO
• Select YES
 
QUIT:YES
• Confirm action…
R
h2:50
Table of commands
(See next page.)
