7-3
CH 7/ View Event Data
View data using
Events, Trend
Follow these steps to display event data.
In this chapter
This chapter covers the following topics.
Action... Result...
STEP 1: Events and Trend are
accessible from the Home screen.
Note that event data will be
available for display while
monitoring or upon reading a
stored file from the data card.
A monitoring status message
appears on the top section of the
screen. Refer to Chapter 5 Start
Menu - Section C Monitor Same
Circuit on page 5-24 for the
procedure on how to capture
events by turning monitoring on.
•Press Events to view event list,
graphs and waveform/rms
display. Proceed to Section A -
Events on page 7-4.
•Press Trend to trend journal
data and view time plots.
Proceed to Section B - Trend
on page 7-17.
MARK002pg
Section Topics See Page
A Events 7-4
B Trend 7-17
