1-5
CH 1/ Getting Started
4400 Controls, Indicators, and Connectors
Dimensions
4400 is a self-contained, portable instrument weighing less than 4 pounds and
measuring 8" (20.3 cm) deep by 12" (30.5 cm) wide by 2.5" (6.4 cm) high. This section
identifies and describes the controls, indicators, and connectors on all panels of the
4400 shown with rubber boot installed.
Top View
Front View
Rear View
Bottom View
