B-12
TR2510 Current Probe
TR2510 Current Probe
Guidelines
To achieve the rated accuracies, follow these guidelines:
The conductor must be at a right angle to the probe.
The conductor must be centered in the probe core.
The jaw contact surfaces must be clean and properly aligned.
Specifications
Range
: 0.1 to 10 Arms
Accuracy (at 60 Hz)
: 0.1 to 10A, ±1% reading ±0.01A
Working voltage
: 600 V max.
Frequency range
: 40 to 3000 Hz
Output signal
: 150 mV/A
Maximum conductor size
: 0.78" (20 mm)
Phase shift (at 60 Hz)
:
1 to 5A less than 1º
5 to 10A less than 1.5º
Operating temperature
: 14 to 131 ºF (-10 to 55 ºC)
Storage temperature
: -40 to 158 ºF (-40 to 70 ºC)
Dimensions
: 5.47 x 2.00 x 1.18” (139 x 51 x 30 mm)
Weight
: 6.5 oz. (180 g)
NOTE
Current probe TR2510 can be used interchangeably with TR2510A.
