8-2
Overview
Section A
EN50160
Overview
What is
EN50160?
EN50160 is a European standard that stipulates the voltage characteristics that can be
expected in public distribution networks. The QOS functionality is equipped with
monitoring and setup protocols to meet the measurements required for EN50160
monitoring. EN50160 specifies that various parameters must be within a specified
percentage for 95% of the standard one week monitoring period.
EN50160
monitoring
mode
EN50160 will be able to display data when the instrument has been configured to
monitor EN50160 Power Quality. Refer to Chapter 5 Start Menu - Section B Wizard
Setup - Monitoring Mode on page 5-18 for the procedure on how to turn EN50160
Power Quality monitoring on.
In this section
The following topics are covered in this section.
Topic See Page
EN50160 Measurement Parameters
EN50160 Compliance Limits
Compliance Statistical Bar Chart
Compliance History
Event Statistics
Min/Max Table for Power Frequency and RMS Voltage
8-3
8-5
8-8
8-11
8-13
8-15
