Dranetz PowerGuide 4400 - Generic Circuit

E-12
Generic Circuit
Generic Circuit
Introduction
In the Generic circuit connection, the 4400 uses voltage channels A, B, C, and D as
differential inputs. Current probes are connected to channels A, B, C, and D.
Connection
diagram
