B-2
General
General
Dimensions
Size
: 12” Width x 2.5” Height x 8” Depth (30 x 6.4 x 20.3 cm)
Weight
: 3.8 pounds
Environmental
Operating
: 0 to 50 °C (32 to 122 °F)
Storage
: -20 to 55 °C (4 to 131 °F)
Humidity
: 0 to 95% non-condensing; indoor use
Altitude
: 2000 m (6560 ft) maximum
System Time
Clock
Crystal controlled; 1 second resolution
Event time clock displays to 1 msec resolution
Time displayed in analog or digital (12 or 24 hour) format
Accurate to 60 seconds per month
Compact Flash
Data Card
Sizes range from 32MB to 128MB
Power
Requirements
Use ONLY the external power supply provided with the unit for operation and battery
charging. Use of any other power supply is not recommended.
Voltage
: 90-264V AC, 45-66 Hz
Consumption
: 20 watts maximum
Field replaceable batteries
: More than 2 hours run-time (3 hours typical) when fully
charged.
Input resistance
Voltage input
: 16 MΩ Line to Line
Current input
: 400 kΩ
