1-11
CH 1/ Getting Started
Install data card
to 4400
The procedure below specifies how to install the data card containing the latest
firmware upgrade to the 4400.
Step Action
1 Make sure that the unit is off. If not, press the 4400 On/Off power button
to turn unit off.
2 Remove the data card from its protective holder and check that the plug
end of card is clean and free of any obstruction.
NOTE: If plug end of card is dirty, clean with static-free, dry, low pressure
air to remove any foreign material causing obstruction of the plug holes.
3 At the bottom of the unit, position the data card with the label facing up
and the plug end facing the top slot (Data Card Slot 1). Make sure that
there are no other cards in the unit except for the data card.
4 Insert the card fully into the top slot (Data Card Slot 1) until resistance is
felt, then press firmly until the card engagement is felt.
NOTE: Do not force the card further into the slot if no card engagement is
felt. Remove card and check if there is foreign object on or in the plug end
of the card. Remove any obstruction. Reinsert program card and repeat
card engagement. If card cannot be engaged, STOP all further action and
call Dranetz
Technical Support at 1-800-372-6832 for assistance.
5 Turn the unit on by pushing the on/off button. The loader should display
“Booting from program card”. If not, call Dranetz
Technical Support
for assistance.
6 The instrument will prompt the user to verify whether or not to upgrade
the firmware. Press Yes and the upgrade procedure will commence. Do
not turn the power off nor remove the data card while firmware upgrade is
in progress.
7 If no errors were detected, a window displaying “Installation Complete”
will pop up. Remove the data card from the unit.
