3-7
CH 3/ View Real Time Data
Standard meter
list (continued)
Standard Tab Parameter Name Label
Demand Active Power Demand Active Power Demand
Apparent Power Demand Apparent Power Demand
Reactive Power Demand Reactive Power Demand
RMS Current Demand Phase A RMS Current Demand Ph A
RMS Current Demand Phase B RMS Current Demand Ph B
RMS Current Demand Phase C RMS Current Demand Ph C
RMS Current Demand Average RMS Current Demand Avg
Energy
(for A, B, C, D,
Total)
Watt Hours Watt Hrs
Volts Ampere Hours VA Hrs
Volts Ampere Reactive Hours VAR Hrs
Harmonics
(for A, B, C, D)
Voltage Total Harmonic Distortion V THD
Current Total Harmonic Distortion I THD
RMS Harmonic Current RMS I Harm
Harmonic Power Unsigned Harm Pwr Unsigned
Flicker
(for A, B, C)
Short Term Flicker Pst
Long Term Flicker (Sliding) Plt (Slide)
Long Term Flicker Plt
