Vigor2960 Series User’s Guide
169
Each item will be explained as follows:
Item Description
Add
Add a new group profile for IP filter.
Edit
Modify the selected profile.
To edit a profile, simply select the one you want to modify
and click the Edit button. The edit window will appear for
you to modify the corresponding settings for the selected
rule.
Delete
Remove the selected profile.
To delete a rule, simply select the one you want to delete and
click the Delete button.
Refresh
Renew current web page.
Move Up
Change the order of selected profile by moving it up.
Move Down
Change the order of selected profile by moving it down.
Profile Number Limit
Display the total number of the profiles to be created.
Group
Display the name of the IP filter group profile.
Enable
Display the status of the profile. False means disabled; True
means enabled.
Comment
Display the description for such profile.
H
H
o
o
w
w
t
t
o
o
c
c
r
r
e
e
a
a
t
t
e
e
a
a
n
n
I
I
P
P
F
F
i
i
l
l
t
t
e
e
r
r
g
g
r
r
o
o
u
u
p
p
To build an IP group containing IP filter rules, please follow the steps:
1. Open Firewall>>Filter Setup and click the IP Filter tab.
2. Simply click the Add button.
3. The following dialog will appear.
Available parameters are listed as follows:
Item Description
Group
Type the name of the IP filter group.
Enable
Check the box to enable this profile.
Comment
Give a brief description for the profile.
