Vigor2960 Series User’s Guide
304
If you choose IPsec as the Type, you will get the following screen:
Available parameters are listed as follows:
Item Description
Profile
Display the name of the VPN profile.
Enable
Check this box to enable such profile.
WAN Profile
Choose a wan profile to be used by such profile.
Local IP/Subnet
Mask
Type the IP address and subnet mask of local host.
Local Next Hop
Specify the gateway for WAN interface. Usually, use the
default setting (leave it in blank).
Remote Host
Type the WAN IP address for the remote host.
Remote IP / Subnet
Mask
Type the LAN IP address and LAN subnet mask for the
remote host.
More Remote
Subnet
Add more remote subnet in this field if required.
Auth Type
The authentication to be used by Pre-Shared Key or RSA
Signature. Choose PSK or RSA for such profile.
Preshared Key
Type a pre-shared key for authentication if PSK is selected
as Auth Type.
Security Protocol
Choose ESP to specify the IPsec protocol for the
Encapsulating Security Payload protocol. The data will be
encrypted and authenticated. Choose AH to specify the IPsec
protocol for the Authentication Header protocol. The data
will be authenticated but not be encrypted.
DPD Delay
DPD means dead peer detection. It is a keep-alive timer. A
To Next Page
