VigorAP 910C User’s Guide
127
mode will bring up different parameters (e.g., WEP keys, Pass
Phrase) for you to configure.
Encryption Type for
Open/Shared
This option is available when Open/Shared is selected as
Security Mode.
Choose None to disable the WEP Encryption. Data sent to the
AP will not be encrypted. To enable WEP encryption for data
transmission, please choose WEP.
WEP Keys - Four keys can be entered here, but only one key
can be selected at a time. The format of WEP Key is restricted
to 5 ASCII characters or 10 hexadecimal values in 64-bit
encryption level, or restricted to 13 ASCII characters or 26
hexadecimal values in 128-bit encryption level. The allowed
content is the ASCII characters from 33(!) to 126(~) except '#'
and ','.
Encryption Type for
WPA/PSK and
WPA2/PSK
This option is available when WPA/PSK or WPA2/PSK is
selected as Security Mode.
Select TKIP or AES as the algorithm for WPA.
Pass Phrase
Either 8~63 ASCII characters, such as 012345678 (or 64
Hexadecimal digits leading by 0x, such as
"0x321253abcde...").
Connection Type
Choose DHCP or Static IP as the connection mode.
DHCP – The wireless station will be assigned with an IP from
Vigor AP.
Static IP – The wireless station shall specify a static IP for
connecting to Internet via Vigor AP.
Device Name
Type a name for the AP as identification. Simply use the
default name.
