%3*45&&.7BQPSMPHJD*OTUBMMBUJPOBOE0QFSBUJPO.BOVBMt1BHF

[

1SFJOTUBMMBUJPO$IFDLMJTU

Figure 9-1:

Vapor-logic4 terminal block detail and connection instructions

Terminal block plug.

Make connections

when the plug is

attached to the

board, or remove for

easier access. Pull

plug straight up to

remove.

Tighten screw after

wire is inserted.

Maximum torque is

3 in-lb (0.34 N-m)

Remove insulation

from end of wire

and insert wire here.

P11

P12

P13

P14

P15

P16

SDU

Triac PV/CA24

VAC

CAsw

VAC

PVsw

TS24

VDC

DHL

VDC

24VAC AFsw

N.O.

C N.C.24VDC

Vapor-logic4 board detail

(see also Figure 5-1)
