Table 71-1:
Interoperability variable and object names (continued)
Variable name and
BACnet object name
Read Only
(RO) or
Read Write
(RW)
Modbus
register
number*
BACnet
Object
Type and
Instance
LonTalk variable
names**
Description Units Range
I-P
units
SI units
I-P
units
SI units
Faults and alarms (cont.)
Alarm_demand_sig_out_of_range RW
DV-7
7
BV-07 nvoAlrmDemndSgnl
See Table 49-1,
Alarms menu
-- -- -- --
Alarm_duct_RH_sig_out_of_range RW
DV-8
8
BV-08 nvoAlrmDuctRHsig
Alarm_aux_temp_sens_out_of_rnge RW
DV-9
9
BV-09 nvoAlrmAuxTemp
Alarm_water_probe_miswired RW
DV-10
10
BV-10 nvoAlrmProbeWire
Alarm_water_probe_failed RW
DV-11
11
BV-11 nvoAlrmProbeFail
Alarm_excess_fill_time RW
DV-12
12
BV-12 nvoAlrmFillTime
Alarm_excess_refill_time RW
DV-13
13
BV-13 nvoAlrmRefilTime
Alarm_tank_not_draining RW
DV-14
14
BV-14 nvoAlrmNoDrain
Alarm_excess_water_no_demand RW
DV-15
15
BV-15 nvoAlrmXessWater
Alarm_no_SDU_airflow RW
DV-16
16
BV-16 nvoAlrmNoSDUair
Alarm_no_power_vent_airflow RW
DV-17
17
BV-17 nvoAlrmPrVentAir
Alarm_no_combustion_airflow RW
DV-18
18
BV-18 nvoAlrmNoCombAir
Alarm_blocked_flue RW
DV-19
19
BV-19 nvoAlrmBlockdFlu
Alarm_burner_1_failed RW
DV-20
20
BV-20 nvoAlrmBurner1
Alarm_burner_2_failed RW
DV-21
21
BV-21 nvoAlrmBurner2
Alarm_burner_3_failed RW
DV-22
22
BV-22 nvoAlrmBurner3
Alarm_burner_4_failed RW
DV-23
23
BV-23 nvoAlrmBurner4
Alarm_ignition_module_1_failed RW
DV-24
24
BV-24 nvoAlrmIgnitMod1
Alarm_ignition_module_2_failed RW
DV-25
25
BV-25 nvoAlrmIgnitMod2
Alarm_ignition_module_3_failed RW
DV-26
26
BV-26 nvoAlrmIgnitMod3
Alarm_ignition_module_4_failed RW
DV-27
27
BV-27 nvoAlrmIgnitMod4
Alarm_blower_1_failed RW
DV-28
28
BV-28 nvoAlrmBlower1
* See Note 1 on Page 76.
** See Note 2 on Page 76.
Continued
