Operation
Table 71-1:
Interoperability variable and object names (continued)
Variable name and
BACnet object name
Read Only
(RO) or
Read Write
(RW)
Modbus
register
number*
BACnet
Object
Type and
Instance
LonTalk variable
names**
Description Units Range
I-P
units
SI units
I-P
units
SI units
Faults and alarms (cont.)
Alarm_blower_2_failed RW
DV-29
29
BV-29 nvoAlrmBlower2
See Table 49-1,
Alarms menu
-- -- -- --
Alarm_blower_3_failed RW
DV-30
30
BV-30 nvoAlrmBlower3
Alarm_blower_4_failed RW
DV-31
31
BV-31 nvoAlrmBlower4
Alarm_gas_valve_1_failed RW
DV-32
32
BV-32 nvoAlrmGasValve1
Alarm_gas_valve_2_failed RW
DV-33
33
BV-33 nvoAlrmGasValve2
Alarm_gas_valve_3_failed RW
DV-34
34
BV-34 nvoAlrmGasValve3
Alarm_gas_valve_4_failed RW
DV-35
35
BV-35 nvoAlrmGasValve4
Alarm_low_water RW
DV-36
36
BV-36 nvoAlrmLowWater
Alarm_foaming_fault_2 RW
DV-37
37
BV-37 nvoAlrmFoaming2
Alarm_Current_Sense1_ Out_Of_Range RW
DV-51
51
BV-51 nvoAlrmCurSense1
Alarm_Current_Sense2_ Out_Of_Range RW
DV-52
52
BV-52 nvoAlrmCurSense2
Alarm_Overcurrent RW
DV-53
53
BV-53 nvoAlrmOverCur1
Alarm_Supply_Water RW
DV-54
54
BV-54 nvoAlrmSupplyH201
Alarm_Foaming_Fault RW
DV-55
55
BV-55 nvoAlrmFoaming1
Alarm_Overcurrent_2 RW
DV-57
57
BV-57 nvoAlrmSupplyH202
Alarm_Supply_Water_2 RW
DV-58
58
BV-58 nnvoAlrmSupplyH202
* See Note 1 on Page 76.
** See Note 2 on Page 76.
Continued
