[551]-[564] - PGM Partition Assignment
The PC1616/PC1832/PC1864 has a 8-bit toggle field per output
that determines which partitions the output is assigned to (outputs
PGM 1-14). Each bit corresponds to a Partition in each PGM’s
toggle mask. This field is supported by PGMs that have multiple
partition capabilities (i.e. Command Outputs, Away Arming). It
does not affect system outputs (i.e. Ground Start Pulse).
5.8 International Programming
[700] - Automatic Clock Adjust
The value entered here adds or subtracts seconds at the end of
each day to compensate for Crystal/Ceramic Resonator inaccura-
cies. Valid entries are 00-99 with 60 seconds being the default
minute. To determine the value to be programmed in this section
perform the following:
Monitor the time lost by the panel over a period of time.
Calculate the average amount of time per day that the
panel gains or loses.
Add or Subtract this value (seconds) from 60 and enter the
value.
Example #1:
The clock loses an average of 9 seconds per day. Solution:
Program the panel to adjust the clock by 51 seconds (instead of the default 60
seconds) for the last minute of each day in section [700]. This will speed up the
panel’s clock by 9 seconds, correcting the problem.
Example #2: The clock gains an average of 11 seconds per day. Solution:
Program the panel to adjust the clock by 71 seconds (instead of the default 60
seconds) for the last minute of each day in section [700]. This will slow down
the panel’s clock by 11 seconds, correcting the problem.
NOTE: If the Auto-arm time is set for 23:59, any change to the
Clock Adjust option will directly affect the Auto-arm pre-alert
time.
PGM Output Types [19]-[22]
5 Access Code Options ON Code Required Access Code Required for Activation.
OFF No Code Required No Access Code Required for Activation.
PGM Output Types [09] System Trouble
1 Service Required Low Battery, Bell Circuit Trouble, General System Trouble (PC5204 AUX failure, PC5204 Output #1
Trouble, Camera Trouble, Home Automation Trouble, PC5400 Off-Line), General System Tamper,
General System Supervisory, RF Jam, PC5204 Low Battery, PC5204 AC Failure
2 AC Fail AC Trouble
3 Telephone Line Fault TLM Trouble
4 Communications (Failure) FTC Trouble
5 Zone (Fire) Fault Zone Fault, Fire Trouble
6 Zone Tamper Zone Tamper
7 Zone Low Battery Zone Low Battery Trouble
8 Loss of Clock Loss of Time Trouble
PGM Output Types [10] System Event
1 Burglary Delay, Instant, Interior, Stay/Away, and 24 Hour Burg Zone Types
2 Fire [F] Key, Fire Zone
3 Panic [P] Key and Panic zones
4 Medical [A] Key, Medical and Emergency zones
5 Supervisory Supervisory, Freeze and Water zones
6 Priority Gas, Heat, Sprinkler and 24 Hour Latching Tamper zones
7 Holdup Holdup Zones and Duress Alarms
8 Output Options ON Output Follows PGM Timer The output will activate for the period of time programmed for the
PGM Output Timer.
OFF Output is Latched The output will be active until a valid access code is entered.
NOTE: If a System Event PGM is programmed to follow the Command Output Timer, all
attributes must be enabled.
NOTE: These are the attributes available for the System Event PGM option. The output will
activate if any of the corresponding alarm types occur on the system.
PGM Output Type [31] Alternate Communicator Output
1 Fire [F] Key, Fire Zone
2 Panic [P] Key and Panic zones
3 Burglary Delay, Instant, Interior, Stay/Away, and 24 Hour Burg Zone Types
4 Openings/Closings Opening, Closing
5 Zone Auto-Bypass Zone Auto-Bypass
6 Medical Events Only [A] Key, Medical and Emergency zones
7 Police Code Output Police Code
8 Output Options ON Pulsed The output will pulse when the selected condition is true
OFF Latched The output will latch when the selected condition is true. The output will latch until a valid
access code is entered.
PGM Output Type [32] Open After Alarm (Abort Code)
1 -7 For Future Use
8 Output Options ON 5 Second Pulse The output will activate for the duration programmed in for the PGM Output Timer
in Section [164]. This default period is 5 seconds.
OFF Output is Latched The output will activate when an opening after alarm occurs. The output will
latch until a valid access code is entered
